Dear all,

This edition of the quarterly newsletter will highlight our extension of our portfolio, specifically with the SoC version of the Sargon board, and the Lite version of the COMXpress board. Happy reading !

Sargon Stratix® 10 SoC FMC+ PCIe board – SX version

The SoC version of this board allows the developer to use the features of the SoC chip to ease development and increase system integration.

• Intel® Stratix® 10 SX 1650 KLEs
• PCIe Gen3 x16
• Board Management Controller (BMC) for monitoring, NOR Flash and clock programming
• 1x FMC+ (VITA57.4) interface with 24 transceivers
• GPIO and transceiver extension connector
• 48 dedicated HPS IO connector (daughter board for SX)

• High Performance Computing
• IP & ASIC Prototyping

> You also can discover here the original version with GX 2800 KLE FPGA

The COM Express Basic module is a small form factor FPGA board with an embedded SoC.

The Lite version of the board is based on the Intel® Stratix® 10 SX 1100 KLE FPGA, allowing a significant cost reduction with the best-in-class technology.

• COM Express Basic form factor Module, Type 7 pinout
• Intel® Stratix® 10 SX Technology – 2800 or 1100 KLE density
• Designed for High Performance Computing and Acceleration
• 32 PCI Express lanes
• IO and Transceiver extension connector

• IP prototyping
• Industrial
• Military and Aerospace
• Test & Measurement
• Machine and Intelligent Vision
• Video Broadcast and video application
• HPC and data center

You also can discover here the Turbo version, 2800 KLE FPGA

The objective of the demo is to show the loopback to and from Stratix® 10 FPGA SerDes, through optics FMC connectivity and FireFly cable MPO. The good signal integrity is demonstrated with the creation of a Quartus Eye Diagram.

> See the demo video
